Din 2565 - Din 2566 Flanges

Din 2565 - Din 2566 Flanges

Product Details:

  • Usage Industrial
  • Grade Multple Grades Available
  • Features Premium Quality
  • Fittings Flanges
  • Surface Other
  • Click to View more
X

Din 2565 - Din 2566 Flanges Price And Quantity

  • 100 Piece

Din 2565 - Din 2566 Flanges Product Specifications

  • Other
  • Multple Grades Available
  • Industrial
  • Flanges
  • Premium Quality

Din 2565 - Din 2566 Flanges Trade Information

  • Cash in Advance (CID)
  • 5000 Piece Per Month
  • 7 Days
  • All India

Product Description

Din 2565 PN 6 (in mm)

Nominal pipe size

Flange Dia

Flange I.D

Thk of Flange

Dia of circle

Length through hub

Dia of hub

Dia of R/F

Thk of R/F

No of

Dia of bolt holes


DN

D

D5

B

K

H1

D3

D4

F

Holes

D2

KG

6

65

11.7

10

40

18

18

25

2

4

11.5

0.19

8

70

15.0

10

45

18

22

30

2

4

11.5

0.23

10

75

17.70

12

50

20

25

35

2

4

11.5

0.32

15

80

22.00

12

55

20

30

40

2

4

11.5

0.37

20

90

27.60

14

65

24

40

50

2

4

11.5

0.58

25

100

34.40

14

75

24

50

60

2

4

11.5

0.73

32

120

43.10

14

90

26

60

70

2

4

14.0

1.05

40

130

49.00

14

100

26

70

80

3

4

14.0

1.20

50

140

61.10

14

110

28

80

90

3

4

14.0

1.54

65

160

77.10

14

130

32

100

110

3

4

14.0

1.87

80

190

90.30

16

150

34

110

128

3

4

18.0

2.78

100

210

115.90

16

170

38

130

148

3

4

18.0

3.07

150

240

170.50

18

200

40

160

178

3

8

18.0

4.33

200

285

221.80

18

225

44

185

202

3

8

18.0

4.81



Din 2566 PN 16 (in mm)

Nominal pipe size

Flange Dia

Flange I.D

Thk of Flange

Dia of circle

Length through hub

Dia of hub

Dia of R/F

Thk of R/F

No of

Dia of bolt holes


DN

D

D5

B

K

H1

D3

D4

F

Holes

D2

KG

6

75

11.7

12

50

18

20

32

2

4

11

0.33

8

80

15.0

12

55

18

25

38

2

4

11

0.39

10

90

17.70

14

60

20

30

40

2

4

14

0.56

15

95

22.00

14

65

20

35

45

2

4

14

0.62

20

105

27.60

16

75

24

45

58

2

4

14

0.92

25

115

34.40

16

85

24

52

68

2

4

14

1.10

32

140

43.10

16

100

26

60

78

2

4

18

1.59

40

150

49.00

16

110

26

70

88

3

4

18

1.77

50

165

61.10

18

125

28

85

102

3

4

18

2.41

65

185

77.10

18

145

32

105

122

3

4

18

3.13

80

200

90.30

20

160

34

118

138

3

4

18

3.95

100

220

115.90

20

180

38

140

158

3

4

18

4.38

125

250

143.80

22

210

40

168

188

3

8

18

5.99

150

285

170.50

22

240

44

196

212

3

8

22

7.42
