Butt Weld Bend And Elbows

Butt Weld Bend And Elbows

Product Details:

  • Features Premium Quality
  • Material Stainless Steel
  • Standard ASTM
  • Outer Diameter 1/2 Millimeter (mm)
  • Usage Industrial
  • Click to View more
X

Butt Weld Bend And Elbows Price And Quantity

  • 100 Piece

Butt Weld Bend And Elbows Product Specifications

  • Premium Quality
  • ASTM
  • Industrial
  • Stainless Steel
  • 1/2 Millimeter (mm)

Butt Weld Bend And Elbows Trade Information

  • Cash in Advance (CID)
  • 5000 Piece Per Month
  • 7 Days
  • All India

Product Description

Specification

Dimensions of Buttweld Elbows (ANSI B 16.9) (in mm)





Center of End

Nom. Pipe
Size

O.D.
D

900 L/R
A

45 S/R
B

90 S/R
A



Min

Nom

Max

Min

Nom

Max

Min

Nom

Max

Min

Nom

Max

1/2

20

21

22

36

38

40

14

16

18

-

-

-

3/4

26

27

28

27

29

31

9

11

13

-

-

-

1

32

33

34

36

38

40

20

22

24

23

25

27

1 1/4

41

42

43

46

48

50

23

25

27

30

32

34

1 1/2

47

48

49

55

57

59

27

29

31

36

38

40

2

59

60

61

74

76

78

33

35

37

49

51

53

2 1/2

72

73

74

93

95

97

42

44

46

62

64

66

3

88

89

90

112

114

116

49

51

53

74

76

78

4

113

114

116

150

152

154

62

64

66

100

102

104

5

140

141

144

188

190

192

77

79

81

125

127

129

6

167

168

171

227

229

231

93

95

97

150

152

154

8

217

219

221

303

305

307

125

127

129

201

203

205

10

270

273

277

379

381

383

157

159

161

252

254

256

12

321

324

328

454

457

460

187

190

193

302

305

308

14

353

356

360

530

533

536

219

222

225

353

356

359

16

403

406

410

607

610

613

251

254

257

403

406

409

18

454

457

461

683

686

689

283

286

289

454

457

460

20'

503

508

514

759

762

765

315

318

321

505

508

511

24

605

610

616

911

914

917

378

381

384

607

610

613



Dimensions of Buttweld Bends (ANSI B 16.28) (in mm)





Center of Center

Back to Face

Nom. Pipe
Size

O.D.
D

1800 L/R
A

180 S/R
A

180 L/R
K

180 S/R
K



Min

Nom

Max

Min

Nom

Max

Min

Nom

Max

Min

Nom

Max

Min

Nom

Max

1/2

20

21

22

69

76

83

-

-

-

41

48

55

-

-

-

3/4

26

27

28

50

57

64

-

-

-

36

43

50

-

-

-

1

32

33

34

69

76

83

44

51

58

49

56

63

34

41

48

1 1/4

41

42

43

88

95

102

57

64

71

63

70

77

45

52

59

1 1/2

47

48

49

107

114

121

69

76

83

76

83

90

55

62

69

2

59

60

61

145

152

159

95

102

109

99

106

113

74

81

88

2 1/2

72

73

74

184

191

198

120

127

134

125

132

139

93

100

107

3

88

89

90

222

229

236

145

152

159

152

159

166

114

121

128

4

113

114

116

298

305

312

196

203

210

203

210

217

152

159

166

5

140

141

144

374

381

388

247

254

261

255

262

269

190

197

204

6

167

168

171

450

457

464

298

305

312

306

313

320

230

237

244

8

217

219

221

603

610

617

399

406

413

407

414

421

306

313

320

10

270

273

277

752

762

772

498

508

518

511

518

525

384

391

398

12

321

324

328

904

914

924

600

610

620

612

619

626

460

467

474

14

353

356

360

1057

1067

1077

701

711

721

704

711

718

526

533

540

16

403

406

410

1209

1219

1229

803

813

823

806

813

820

603

610

617

18

454

457

461

1362

1372

1382

904

914

924

907

924

921

679

686

693

20

503

508

514

1514

1524

1534

1006

1016

1026

1009

1016

1023

755

762

769

24

605

610

616

1819

1829

1839

1209

1219

1229

1212

1219

1226

907

914

921


These pipe fittings work perfectly to stop fluid leakage and are known to be ideal compound connection that pipes can have.

Elbow: The Butt Weld Elbow can be 45 Degrees, 90 Degrees and 180 Degrees

Bend: The Bend can be 180 Degree L/R Return Bend and 180 Degree S/R Return Bend
